Aggressive and entirely progressive. It provides the maximum of design expression and of technical contents. The special design of the seat stay provides a high capacity for absorbing the shocks. This frame offers performance on the verge of a competitive level, but at the same time, it is easy to ride on every kind of course and in all weather condition.
[EXCLUSIVE DETAILS]
Ø 100mm of stable pedaling rear travel.
l A.S.A.P™ Kinematics for XC
? High Reactivity to rider-inputs
=bump absorption
? Low Reactivity to rider-inputs
=pedaling efficiency
l Maximum lateral stiffness
l Minimum standover height on all frame sizes
l Element-specific Fox Shox Float Series
l Open-Source Pivot (OSP) Position
? Sealed cartridge bearings
l CNC Shock-Box & Swing-Link
l Element 36-OS™ ø1-1/8” headset included
[DETAILS]
l Materials: AL7005
l Colors:
? Gloss-white / Hard-gold
? Gloss-black / Hard-gold
l Frame Weight (18”):~2.3kg (w/o shock)
l Element E.G.S.™ geometry for aggressive XC riding
? Standard Sizes: 16.5” / 18” / 19.5”
l Available As: Framest/ Complete-Bike
[INTENDED USE]
l XC / Trail / Adventure / Marathon
l Suggested Forks (80mm~100mm travel):
? Fox 32F Series
|
